ID # 9579478647004 Model # NEFBD50HE
Napoleon CLEARion Elite See-Through Electric Fireplace — 50" & 60"
- Liftgate freight delivery. Delivered by freight to the lower 48 with liftgate service. Inspect the shipment before you sign; if anything is damaged, note it on the delivery receipt and call us right away. We'll take it up with the distributor and manufacturer.
- 30-day returns on unused, unassembled items (20% restocking fee; return freight at your cost). Terms
- Full manufacturer warranty, which applies because we are an authorized Napoleon dealer.
- See the delivery and order process
Send your opening, fuel type, voltage, or project details and we'll confirm the right model before you order.
Owner-run authorized Napoleon dealer · Albion, PA · Mon–Fri 9 AM–8 PM ET · americanhearthsupply@americanhearthsupply.com
Build Your Napoleon
Napoleon's options for this fireplace, matched to the model you've selected above. Each option is a separate Napoleon part at its own price — nothing here is bundled or discounted. Not sure what you need? Call (814) 440-4817 and we'll check the build against the manual.
Fitment: Napoleon CLEARion Elite manual W415-2107, section 8
About this model
The CLEARion Elite is Napoleon's see-through built-in electric fireplace — flame visible from both rooms, with no venting, no gas line and no chimney.
Why See-Through Electric
A gas see-through needs venting and a gas supply. The CLEARion Elite needs a framed opening and a dedicated electrical circuit.
Where It Works
- Living room to dining room
- Bedroom to ensuite
- Room divider walls in open-concept spaces
The CLEARion Elite is for indoor use only — both sides must be indoors.
Specifications
| Model | NEFBD50HE | NEFBD60HE |
|---|---|---|
| Viewing area | 43 5/8" × 12" | 53 1/2" × 14" |
| Unit width × height × depth | 50" × 18 3/8" × 9" | 60" × 20 7/16" × 9 3/16" |
| Heat output | 5,000 BTU on 120V · 10,000 BTU on 240V | 5,000 BTU on 120V · 10,000 BTU on 240V |
| Heat per side | 750 W each side on 120V · 1,500 W each side on 240V, controlled independently | |
| Electrical | Hardwired, 120V or 240V, dedicated 15 amp grounded circuit | |
| Warranty | Napoleon 3 Year Limited Warranty (labour covered in the first year) | |
Sources: Napoleon installation and operation manual W415-2107 and specification sheets W415-2032 (50") and W415-2914 (60").
Controls
Flame without heat, and heat on one side only. The flame runs with the heater off, and each side of the fireplace has its own heater control — heat one room, both rooms or neither.
- Privacy glass — half transparent, fully transparent or opaque
- Orange flame — 5 brightness levels, including off
- Blue flame — 5 brightness levels, including off
- Flame speed — 5 settings
- Ember bed — 15 colours or auto-cycle, 5 brightness levels or fade
- Heat — off, fan only, or heat, set separately for each side
- Thermostat — 64°F to 82°F
- Timer — 30 minutes to 8 hours
- Heater lock-out — child safety feature
- Two remotes — one for each side, plus a touch panel
Source: Napoleon manual W415-2107, section 5.
What's in the box / not included
- Two remote controls
- Acrylic crystals and topaz glass media
- Front and back media trays
- Mounting brackets, magnetic buttons, screws and strain relief
Not included
- Trim kits — see below
- Additional crystal media
Trim and Media Options
| Option | NEFBD50HE | NEFBD60HE |
|---|---|---|
| Black deep trim (both sides) — for 4 1/2" thick walls | NEFBD50HE-DTRM — $389 | NEFBD60HE-DTRM — $439 |
| Stainless steel deep trim (both sides) — for 4 1/2" thick walls | NEFBD50HE-SS-DTRM — $439 | NEFBD60HE-SS-DTRM — $559 |
| Stainless steel trim (both sides) — for standard 8" walls, 50 inch only | NEFBD50HE-SS-TRIM — $499 | Not available for the 60" |
| Large crystals, per bag | W497-0067-SER — $29 (2 bags required) | Call for part number |
Trim options from Napoleon manual W415-2107, section 8.
Before You Order
| Framing (W × H × D) | NEFBD50HE: 49" × 17 15/16" × 8" NEFBD60HE: 59" × 19 15/16" × 8" Framing depth is 4 1/2" when using a deep trim kit |
| Clearances | 0" bottom and sides · 8" to a mantel · 36" front and back to furniture, bedding and other combustibles |
| Finishing material | Up to 1 1/2" thick, finished on both sides of the wall |
| Electrical | Hardwired to 120V or 240V on a dedicated 15 amp grounded circuit |
| Location | Indoor use only |
See-through installs affect framing and finishing in two rooms — decide before drywall. Source: Napoleon manual W415-2107. Always work from the manual before framing.
Documents & Downloads
- Installation and Operation Manual (W415-2107) — NEFBD50HE and NEFBD60HE
- CLEARion Elite 50 Specification Sheet (W415-2032)
- CLEARion Elite 60 Specification Sheet (W415-2914)
- CAD files (.zip): NEFBD50HE · NEFBD60HE
- CLEARion Elite Brochure
All sizes and prices
Prices include freight to the lower 48. Not sure which one? Call or text (814) 440-4817 with your dimensions and we'll confirm the fit.
Learning Center
Guides from our Buying Guides blog related to this product.
Before you order
Questions people ask about this kind of product
Will this fit my wall?
The dimensions on the page are the appliance body; framing and rough-opening sizes are different numbers and come from the manufacturer's installation manual linked on the page. Call or text (814) 440-4817 with your wall width and height and we'll confirm the right size before you order.
Do I need a professional to install it?
Gas appliances: yes, a licensed gas installer, and most jurisdictions require a permit and inspection. Electric fireplaces are simpler but hardwired models need an electrician. We don't install — we supply the manufacturer's installation manual and clearance specs so your installer and inspector have what they need.
What's included, and what do I need to add?
Each product page lists what ships in the box. Log sets, glass media, decorative fronts, mantels and venting kits are usually separate items — tell us what look you want and we'll put the complete build on one quote so it ships together where possible.
Is freight included, and how long until it arrives?
Freight is included to the 48 contiguous states, with liftgate delivery and no surcharges at checkout. Your order typically ships in 1-3 business days, and most deliveries arrive in 1-2 weeks from your order. We provide tracking once it ships, and the carrier calls to schedule delivery. Alaska, Hawaii, U.S. territories and international are quote-only — call before ordering.
What happens if it arrives damaged?
Look the crate over before you sign, write any damage on the delivery receipt (even "box damaged"), take a couple of photos, and contact us right away. For damage you find after unboxing, contact us as soon as you see it. We'll take it up with the distributor and manufacturer.
Can I return it?
Yes, within 30 days of delivery, if it's unused, unassembled and in the original packaging. Approved returns carry a 20% restocking fee and the customer covers return freight unless the return is due to our error or a defect — on a large freight item that is real money, which is exactly why we check the size and setup with you before you order. Special-order and custom-finish items can't be returned. Full terms: Refund policy.
